Weller HAP200 — Hot Air Iron
The Weller HAP200 (Item No.: T0052711699N) is a hot air iron designed for use with WR3M power units. The device operates with 200 W power and 24 V supply, and comes with a round hot air nozzle R 04 with a diameter of 1.2 mm. Temperature control and airflow are specified in the manufacturer's documentation.
Function and Operation
- Power: 200 W.
- Supply voltage: 24 V.
- Temperature range: 50 °C to 550 °C (indicated temperature range in product data).
- Activation: finger switch.
- Maximum hot air flow rate: 15 l/min (depends on tool).
- Included nozzle type: R 04 round, Ø 1.2 mm.
Temperature Precision
The manufacturer specifies a temperature accuracy of ±30 °C. The product datasheet also indicates a temperature range depending on the tool (93–537 °C) as well as converted values in Fahrenheit.
Documentation
Detailed technical information and product data can be found in the manufacturer's datasheet.
See datasheet from manufacturer
Specifications
- Product name: Weller HAP200 (Item No.: T0052711699N)
- Product category: Hot air iron
- Power: 200 W
- Supply voltage: 24 V
- Temperature range: 50 °C – 550 °C
- Temperature accuracy: ±30 °C
- Max. hot air flow: 15 l/min
- Included nozzle: R 04 round Ø 1.2 mm
- Compatible power unit: WR3M
