SEHO Streamline – Automated Material Flow for SMT Production

The SEHO Streamline is designed for the automatic handling and transport of SMD reels between warehouse and production line. The system reduces manual processes, minimises the risk of errors, and ensures that the right components are available at the right time. Integrated with material management systems such as Essemtec Hive, Streamline contributes to more efficient material flow, higher traceability, and fewer production stops in modern electronics manufacturing.

SEHO

Electro Design

Electro Design designs and manufactures automation products for the electronics industry. Since the first conveyor was made in 1987, they have supplied approximately 5000 units to customers worldwide.

  • MB807 single unloader maskine til printplader

    MB807 SINGLE UNLOADER

    Unloads empty or pre-assembled PCBs from a production line into magazines.

  • MB806 SINGLE LOADER maskine til at adskille og loade tomme printplader

    MB806 SINGLE LOADER

    Separates and loads empty or pre-assembled PCBs from a production line into magazines.

  • MB803 automatisk buffermagasin til balance af PCB flow og linjesplitning

    MB803 AUTOMATIC

    The buffer magazine is for balancing PCB flow in FIFO or LIFO buffer mode, it acts as a line splitter in Loader or Unloader mode, or line fusion in Pass Through mode. The magazine can be removed/exchanged at any time.

  • Electro Design MB802 Automatic Unloader til PCB'er

    MB802 AUTOMATIC

    Unloads empty or pre-assembled PCBs automatically, from a production line into magazines.

  • MB801 Automatic Loader maskine til PCB i hvid og grå

    MB801 AUTOMATIC

    Loads empty or pre-assembled PCBs from a production line into magazines.

  • MB785 Board Inverter til automatisk PCB vending i produktionslinje

    MB785 BOARD INVERTER

    The Board Inverter flips a PCB upside down to enable mounting on both sides without manual intervention. A PCB transfer cycle consists of advancement, flip or no-flip, and execution. Up to 10 different board transfer cycles can be stored. The machine is bidirectional and can receive and send PCBs both upstream and downstream.

  • MB780 FIFO/LIFO Buffer enhed fra Electro Design

    MB780 FIFO/LIFO BUFFER

    This buffer unit is designed to balance different capacities in the system by offering PCB escape options in case of errors or slow PCB flow in the connected systems.

  • MB777 Shuttle conveyor system bruges til at forbinde produktionslinjer

    MB777 SHUTTLE

    The shuttle conveyor acts as a link between single-lane and dual-lane production lines. By transferring PCBs sideways on a shuttle, one lane is divided into two, or two lanes are merged into one. The machine consists of a transversal unit and a PCB-carrying shuttle conveyor.

  • MB776 Board Transfer system til opdeling, sammenlægning, og omdirigering af produktionslinjer

    MB776 BOARD TRANSFER

    The Board Transfer System is an advanced solution for dividing, merging or redirecting production lines by transferring PCBs between them. The machine consists of a transverse unit and a PCB-carrying shuttle conveyor.

  • Board action

    Board handling is an important part of production to ensure that components are handled correctly. Electro Design has worked with board handling for over 30 years. Their expertise and products are sought after worldwide. Swedish quality and good service are the hallmarks of Electro Design.

  • Electro Design series

    The MB750 Turn Unit receives PCBs from 1, 2 or 3 input sides, to 1, 2 or 3 output sides. PCB advancement / routing is based on prioritized values via the control panel. The output table's routing can also be controlled by external signals such as good/no good PCB or by a barcode reader.

    The MB775 manual gate conveyor allows people to walk through instead of having to go around a complete line. It consists of two conveyor sections, one fixed and one hinged.

  • Benefits of Electro Design

    • High quality
    • Good service
    • Many years of experience

    To ensure stable board operation, it is essential to choose the right components.
