SPS-ELECTR KT6780H
The KT6780H is a 19"/3U rack-mounted hipot safety analyzer for electrical safety testing. It combines several key tests into one unit, allowing for high-voltage insulation, insulation resistance, ground bond, and substituted leakage current testing in a single workflow. This makes it relevant in production and test environments where electrical products must be checked for compliance with safety requirements.
For AC high-voltage testing, the range is from 100 V to 5,500 V with test and short-circuit current up to 20 mA. For DC high-voltage testing, the range is from 100 V to 6,000 V with test and short-circuit current up to 20 mA. Additionally, it can measure insulation resistance from 100 kΩ to 50 GΩ, and the ground bond test covers 1 A to 32 A as well as 0 Ω to 6 Ω. This provides a good breadth when examining both insulation and protective grounding.
It is also designed for more systematic use in a professional test setup. The manufacturer specifies automatic test sequences, multiple interfaces, and a fully electronic generator, which helps support faster and more precise tests. In this way, the KT6780H fits well when safety tests need to be an integral part of a stable and repeatable process.
Typical applications
- Electrical safety testing in production
- Verification of insulation and high-voltage resistance
- Testing of grounding and protective earth conductor
- Substituted leakage current testing
See data sheet from the manufacturer
See product video from the manufacturer
Specifications
- Manufacturer: SPS-ELECTR
- MPN: KT6780H
- Type: 19"/3U rack hipot safety analyzer
- AC high-voltage test: 100 V to 5,500 V
- AC test/short-circuit current: up to 20 mA
- DC high-voltage test: 100 V to 6,000 V
- DC test/short-circuit current: up to 20 mA
- Insulation resistance: 100 kΩ to 50 GΩ
- DC test voltage for insulation measurement: 100 V to 6,000 V
- Ground bond test: 1 A to 32 A
- Ground bond resistance range: 0 Ω to 6 Ω
- Substituted leakage current test: 50 V to 270 V AC
- Substituted leakage current: up to 10 mA
- Digital interface: 24 VDC input/output, 4 inputs and 4 outputs
- Computer interfaces: Ethernet/LAN and USB
- Supply voltage: 90 V to 250 V
- Frequency: 50 Hz / 60 Hz
- GTIN/EAN: not specified in the verified data
