Product Overview
This soldering tip from WELLER is the Weller RTU 004 C MS. The Weller RTU 004 C MS is an RT Ultra conical soldering tip with a tip diameter of 0.4 mm, designed for high-performance and heavy-duty applications. The tip uses Thermal Core Technology for optimized heat transfer and is classified as Tip Type MS WX. The product is registered as ESD Safe and meets MIL-SPEC / IPC requirements, as stated in the manufacturer's documentation.Product Details
- Product Name: Weller RTU 004 C MS
- Tip Shape: Conical
- Tip Diameter: 0.4 mm
- Tip Type: MS WX
- Technology: Thermal Core Technology
Documentation
Further technical information and confirmation of specifications can be found in the manufacturer's datasheet: View datasheet from manufacturer.
Typical Applications
The following applications are listed in the manufacturer's technical text and describe the purposes for which the Weller RTU 004 C MS is designed:
- Soldering of LED components
- Solar technology
- Soldering of electronic components
- Multi-layer circuits
- Soldering on large heat sinks
- High-frequency PCBs with large dissipaters
Specifications
- Length: 1 in
- Power: 150 W
- ESD Safe: Yes
- Mil-Spec: Yes
- Tip Shape: Conical
- Tip Finder Size Range: 0.1 - 0.4 mm
- Tip Type: MS WX
- Works With: WXUP-MS
- Quantity Per Package: 1
- Product Family: RT Ultra Active Soldering Tips
Content generated using AI – we reserve the right for errors.
Contact HIN for further information about the product.
