STAUBLI FLEXI-E 0.25
The STAUBLI FLEXI-E 0.25 is a highly flexible, single-insulated multi-strand wire with a cross-section of 0.25 mm². It is designed for situations where a thin connecting wire is needed that can still be bent and routed neatly in setups, test environments, and other electrical work.
The conductor consists of 66 fine strands, which is precisely what makes it so flexible in use. At the same time, it has PVC insulation, making it suitable for simple insulated wiring for general installation and connection tasks. The total outer diameter is 1.7 mm, so it takes up relatively little space in a setup.
The wire is rated for AC 500 V and 6 A and has a temperature range from -10 °C to +70 °C. This makes it relevant in professional environments where work is carried out within the parameters and loads specified by the manufacturer. CE, UKCA, and EAC approvals are also indicated.
It is supplied as standard on a 100-meter reel. The color code for blue is 23, so the blue 100 m reel is ordered as 60.7003-10023.
See datasheet from the manufacturer
Specifications
- Manufacturer: STAUBLI
- MPN: 60.7003-10023
- Type: highly flexible, single-insulated multi-strand wire
- Nominal cross-section: 0.25 mm²
- Wire construction: 66 x 0.07 mm
- Conductor diameter: 0.65 mm
- Outer diameter: 1.7 mm
- Insulation material: PVC
- Insulation thickness: 0.5 mm
- Temperature range: -10 °C to +70 °C
- Rated values: AC 500 V, 6 A
- Approvals: CE, UKCA, EAC
- Standard delivery form: 100-meter reel
- Color code: blue = 23
