VDE socket insert — GEDORE 2946467 (VDE 30 15)
Brief description
GEDORE part 2946467 (VDE 30 15) is a VDE socket insert with a 3/8" square drive and a 15 mm 6-point profile. The product is specified in the manufacturer's catalog as the 15 mm variant of the VDE 30 series, with a working length (L) of 46 mm and code 2946467.
Technical characteristics
The description from the manufacturer indicates materials and standards, including that the insert is made of GEDORE vanadium steel 31CrV3 and that the square drive complies with DIN 3120 - C 10 and ISO 1174. The socket insert is insulated and tested up to 1000 V in accordance with EN 60900/IEC 60900. The insulation is a two-layer Check-Tool insulation with an insulation overhang of 16–18 mm.
Documentation
The manufacturer's catalog and technical descriptions are the verified source for the above information.
Specifications
- Manufacturer: GEDORE
- Article number / code: 2946467
- Model designation: VDE 30 15 (GEDORE part 2946467)
- Type: VDE socket insert
- Square drive: 3/8" (specified in manufacturer's catalog)
- Profile: 15 mm 6-point
- Material: GEDORE vanadium steel 31CrV3
- Standards: EN 60900 / IEC 60900 (insulation tested up to 1000 V)
- Insulation: Two-layer Check-Tool insulation
- Insulation overhang: 16–18 mm
- Working length (L): 46 mm (listed in manufacturer's catalog)
