PDR IR-E6 – IR rework system for large PCBs
The PDR IR-E6 is a professional manual rework system designed for large PCBs and high thermal mass applications. The special gantry system provides great freedom of movement over the PCB, allowing rework to be performed right up to the edge of large PCBs.
Large working area and powerful PCB preheating
The system combines 150W focused IR heating with a powerful 3,200W three-zone IR preheater. The split-beam prism system provides precise optical alignment of components and PCBs with up to 50x magnification and a placement accuracy of up to 10 µm.
The IR-E6 handles PCBs up to 460 × 620 mm and components up to 55 × 55 mm. This makes the system particularly relevant for large, complex, and valuable assemblies where both the working area and controlled heat treatment are crucial.
Key features of the PDR IR-E6
-
PCB size up to 460 × 620 mm
-
Gantry system for rework right up to the edges of the PCB
-
150W focused IR heating
-
3,200W three-zone IR preheater
-
Component size up to 55 × 55 mm
-
Split-beam optical component alignment with 50x magnification
-
Placement accuracy up to 10 µm
-
Automatic temperature profiling via ThermoActive software
