STAUBLI X-GL-438
The STAUBLI X-GL-438 is a 4 mm banana plug for in-line mounting, intended for self-assembly of test leads. It is used when a lead needs to be terminated with a plug that can be connected directly to measuring equipment in testing and measurement contexts.
The plug contains a spring-loaded MULTILAM contact, which provides a stable contact surface. Additionally, it features a retractable insulation collar that helps protect against accidental contact. This detail is particularly useful in practical work where leads and equipment are often handled close to live connections.
The plug is rated for 600 V, CAT II, and 32 A. It can be used with cable diameters up to 3.9 mm, corresponding to a maximum of 2.5 mm². The connection to the lead is made via a screw terminal, making it suitable for simple and controlled assembly without special tools.
Stäubli also states that the protective collar provides clearances and creepage distances that allow leads with this plug to be connected to older measuring instruments not yet equipped with safety sockets, up to 600 V, CAT II. This is precisely the kind of detail that makes a difference in the workshop or on the test bench, where different instrument types often need to be used together.
See manufacturer's datasheetTypical applications
- Self-assembly of test leads
- Connection in test and measurement equipment with 4 mm banana connection
- Use when assembling leads for older measuring instruments requiring protected connection
Specifications
- Manufacturer: STAUBLI
- MPN: 66.9584-22
- Type: X-GL-438
- Plug system: 4 mm
- Mounting: in-line
- Connection: screw terminal
- Contact material: CuZn
- Surface treatment: nickel (Ni)
- Rated values: 600 V, CAT II, 32 A
- Max. cable diameter: 3.9 mm
- Max. conductor cross-section: 2.5 mm²
- Outer diameter: 3.9 mm
- Standard: IEC EN 61010-031
