Product Overview
This PIERGIACOM stripping tool, SF 30, is an adjustable wire stripper designed for precise removal of insulation from conductors without damaging the conductor wires. The SF 30 is also available in an ESD-safe version under the designation SF 30 D.Design and Function
- Adjustable stripping for conductors with diameters 0.20–0.64 mm (32–22 AWG).
- The tool's construction consists of 2.5 mm thick steel.
- Built-in elastic component that enables stripping of the cable sleeve without damaging the conductors.
- Handle model: St.
- Weight: 78 g; length: 141 mm.
- ESD version: SF 30 D comes with ESD-safe handles in gray/black (specified as a separate order/item number).
Typical Applications
The SF 30 is used to remove insulation from conductors with diameters in the range of 0.20–0.64 mm (32–22 AWG). The elastic stripping component is specifically described for removing insulation without damaging the conductor wires themselves.Sources
Specifications
- Product name/order code: SF 30 (ESD: SF 30 D).
- Conductor dimension: 0.20–0.64 mm (32–22 AWG).
- Tool length: 141 mm.
- Weight: 78 g.
- Steel thickness: 2.5 mm.
- Handle model: St.
- Function: Elastic stripping component for removing insulation without damaging conductor wires.
- ESD version: SF 30 D with ESD-safe handles (gray/black).
