WIHA 22509 — Bit (Phillips PH1)
Description
The WIHA 22509 is a professional Phillips bit in size PH1 with an E6.3 (1/4") drive. The bit has an overall length of 150 mm and product dimensions stated as 150 x 7 x 6 mm. The material is high-quality chrome-vanadium steel, and the bit is through-hardened. The product is specified according to DIN 3126 and ISO 1173 (Form E6.3).- Phillips profile: PH1
- Drive: E6.3 (1/4")
- Overall length: 150 mm
- Product dimensions: 150 x 7 x 6 mm
- Material: chrome-vanadium steel, through-hardened
- Standards: DIN 3126; ISO 1173 (Form E6.3)
Typical applications
The manufacturer's description indicates the WIHA 22509 for general screw applications in craftsmanship and industry. It covers common fastening tasks where a PH1 bit with an E6.3/1/4" drive is used.Variants and lengths
WIHA specifies extended length variants for the same type of bits in lengths of 50, 70, 90, 110, 127, and 150 mm. The WIHA 22509 is the specified PH1 variant with an overall length of 150 mm.Practical note
The description and technical information are based on the manufacturer's specifications for article number 22509. The WIHA 22509 is used as an interchangeable bit in tools with an E6.3 (1/4") holder and is specified according to the mentioned standards.Specifications
- Product: WIHA 22509
- Manufacturer: WIHA
- Order number: 22509
- Profile: Phillips PH1
- Drive: E6.3 (1/4")
- Overall length: 150 mm
- Product dimensions: 150 x 7 x 6 mm
- Material: chrome-vanadium steel, through-hardened
- Standards: DIN 3126; ISO 1173 (Form E6.3)
- Available lengths (variants): 50, 70, 90, 110, 127, 150 mm
