Product Overview
This two-channel soldering and desoldering station WXD2020 Set 230V (Item No. T0053429399N) from WELLER is supplied as a complete set with the WXDP 120 desoldering tool and WXP 120 soldering iron. The station is specified for 230 V operation and requires connection to an external compressed air supply.
Features
- Two channels: simultaneous operation of desoldering and soldering tools.
- Tools in the set: WXDP 120 (desoldering) and WXP 120 (soldering).
- Temperature range: adjustable from 50 °C to 550 °C (tool-dependent).
- Station power: 200 W (255 W stated as maximum).
- Patented ESD-safe glass display and USB interface for firmware updates, parameterization, and monitoring.
- Automatic standby mode for energy saving.
Typical Applications
The WXD2020 Set 230V is used for soldering and desoldering with the included WXDP 120 and WXP 120 tools. The product description explicitly states these functions and tools.
Documentation
The information in this product text is based on the manufacturer's product description and technical data for the WXD2020 Set 230V published by WELLER.
Specifications
- Product name: WXD2020 Set 230V (Item No. T0053429399N).
- Included tools: WXDP 120 desoldering tool and WXP 120 soldering iron.
- Voltage: 230 V.
- Station power: 200 W (255 W).
- Temperature range: adjustable from 50 °C to 550 °C (tool-dependent).
- Number of channels: 2.
- Requirement: connection to an external compressed air supply.
- Air consumption: 35 l/min.
- Operating pressure: 4–6 bar (54–87 psi).
- Dimensions (L x W x H): 174.0 x 154.0 x 135.0 mm.
- Weight (catalog): 3.80 kg.
- ESD-safe: Yes (patented glass display indicated as ESD-safe).
- USB interface: Yes (for firmware updates, parameterization, and monitoring).
- Other functions: automatic standby mode for tools.
Source: Manufacturer's product description for WXD2020 Set 230V (WELLER).
Content generated using AI – we reserve the right for errors.
Contact HIN for further information about the product.
