Ball bolts Ø20mm x M12 internal thread

Overview

This Kugelanschlussbolzen 63-0101-001 from HORSTMANN is a ball connection bolt specified with internal thread. The product is presented on the manufacturer's product page as a component for the phase fixed point (phasenfestpunkt) and is specified with dimensions, material, and short-circuit notes.

Product Identification

• Manufacturer: HORSTMANN
• Item no.: 63-0101-001
• Product name: Kugelanschlussbolzen

Typical Applications

According to the manufacturer's product page, the Kugelanschlussbolzen 63-0101-001 is specified for use as a phase connection (phasenanschluss) and for busbar screw connection (stromschienenverschraubung). The mentioned function includes:

• Mechanical fixing of the conductor (phasenanschluss).
• Absorption and transfer of electrodynamic forces due to short-circuit currents.

The description on the manufacturer's page also mentions installation requirements, including correct assembly and adherence to prescribed tightening torques to ensure functionality, low contact impedance, and vibration-proof connection.

Material and Construction

Text on the manufacturer's page indicates the material for the straight Kugelanschlussbolzen as E-Cu, verzinnt (electrolytic copper, tinned) and shows official product images on horstmanngmbh.com.

Sources

See product information from the manufacturer

Specifications

• Product: Kugelanschlussbolzen 63-0101-001 (HORSTMANN)
• Ball diameter: Ø 20 mm
• Internal thread: M12
• Material: E-Cu, verzinnt (specified for straight Kugelanschlussbolzen)
• Rated value Ir: 18.7 kA (tr = 1 s) for the configuration Ø20 mm, M12
