CEC 15/4.5 — cross-linked polyolefin end cap
The CEC 15/4.5 from DSG-CANUSA is a cross-linked, adhesive-lined polyolefin end cap designed for sealing and protecting cable ends. The product comes with a thermoplastic adhesive liner that provides an environmental seal around the cable termination and is designed to shrink with a ratio greater than 2:1.
Description and function
- Adhesive-lined end cap with thermoplastic liner for environmental sealing.
- UV-stabilized material with resistance to chemicals and solvents.
- Shrink ratio >2:1; minimum shrink temperature 125°C.
CEC 15/4.5 is specified with an expanded internal diameter of 15.0 mm and a recovered internal diameter of 4.5 mm, as well as a nominal total wall thickness of 2.00 mm. The length as stated in the manufacturer's table is a minimum of 45 mm. The manufacturer's recommended diameter range is 5.0–12.0 mm.
Typical applications
- Sealing of cables against moisture.
- Used as stop-end with an insulation rating up to 1000 V under load.
Documentation
Further technical details and test data can be found in the manufacturer's datasheet:
See datasheet from the manufacturer
Specifications
- Product name: CEC 15/4.5
- Material: PE, modified (cross-linked polyolefin)
- Adhesive-lined with thermoplastic liner
- Shrink ratio: >2:1
- Shrink temperature: 125°C min.
- Continuous operating temperature: -40°C to 100°C
- Expanded internal diameter: 15.0 mm
- Recovered internal diameter: 4.5 mm
- Nominal total wall thickness: 2.00 mm
- Minimum length: 45 mm
- Recommended diameter range: 5.0–12.0 mm
- Dielectric strength: >12 kV/mm
- Tensile strength: 10 MPa
- Elongation: 300% min.
- Rated to 1000V for stop ends under load
