Product Overview
KT-L-4-39 is specified by Stäubli as a component for LM-4A-39 and LM-4N-39 4 mm test plugs. The component's role is documented in Stäubli data, where it is part of the overall design of the stackable, Ø 4 mm plugs with MULTILAM spring contact for self-assembly of leads.Technical Description
This component name (KT-L-4-39) relates to the mechanical/electrical contact point in the LM-4A-39/LM-4N-39 system. According to the manufacturer's information, a MULTILAM spring contact is used in the aforementioned plugs, and the system is specified with the following characteristics, which also apply to the components listed as parts (including KT-L-4-39).- Plug system diameter: 4 mm
- Outer diameter: 3.9 mm
- Plug types are stackable
- Contact principle: spring-loaded MULTILAM for self-assembly of test leads
- Specified conductors: up to 2.5 mm² (LM/LQ 4-39 series)
- Specified ratings for LM-4…-39 plugs: 30 V AC / 32 A and 60 V DC / 32 A
Documentation
The manufacturer's technical data sheet contains the official product data for the LM-4A-39 series, where KT-L-4-39 is listed as a component. For detailed data on the plug series and the specified values, please refer to the manufacturer's publication: See data sheet from manufacturerTypical Applications
- KT-L-4-39 is used as a component in the assembly and self-assembly of test leads in LM-4A-39 and LM-4N-39 4 mm test plugs, as described by Stäubli.Specifications
- Product: KT-L-4-39 (component for LM-4A-39 / LM-4N-39)
- Plug system diameter: 4 mm
- Outer diameter: 3.9 mm
- Contact type: spring-loaded MULTILAM (specified for LM-4A-39/LM-4N-39)
- Wire size (specified for LM/LQ 4-39 series): up to 2.5 mm²
- Ratings (specified for LM-4…-39 plugs): 30 V AC / 32 A and 60 V DC / 32 A
