GW-INSTEK GPT-9801
The GW-INSTEK GPT-9801 is an electrical safety tester for AC withstand testing, which is the type of high-voltage test used to check whether an item can withstand an alternating voltage without breakdown. It is the simple model in the GPT-9800 series, as it only works with AC hipot testing and is therefore designed for tasks where precisely this test function is needed.
The voltage range is from 0.050 kV to 5.000 kV AC, and the frequency can be selected to be 50 Hz or 60 Hz. At the same time, it is designed for a maximum load of 200 VA, and the AC current measurement ranges from 0.001 mA to 40.0 mA. This provides a clear overview of how the item reacts during the test, making the instrument suitable for systematic work with safety requirements and verification.
In practice, some of the built-in safety features also make it interesting in a professional environment. It automatically discharges the item after the test, has an interlock function, zero-crossing turn-on, and ARC detection. These are functions that help make the test process more controlled and protect both equipment and user during operation.
You can find more details about the design and specifications in the datasheet from the manufacturer: See datasheet from the manufacturer
Specifications
- Manufacturer: GW-INSTEK
- MPN: GPT-9801
- Type: Electrical Safety Tester
- Test Function: AC withstand (hipot) test
- AC output voltage range: 0.050 kV to 5.000 kV AC
- Voltage resolution: 2 V
- Frequency: 50 Hz / 60 Hz
- Maximum load: 200 VA (5 kV / 40 mA)
- AC current measurement range: 0.001 mA to 40.0 mA
- Features: Automatic discharge of DUT after test, interlock, zero-crossing turn-on, ARC detection
