GEDORE VDE socket wrench insert VDE 30 8
This VDE socket insert from GEDORE, designated "VDE 30 8" (item no. 2946394), is a manually operated 3/8" drive, 6-point hexagonal insert for twisting tools. The product's purpose and construction are described by the manufacturer and documented on GEDORE's product page (see source below).
Description
The GEDORE VDE socket wrench insert VDE 30 8 is made of chrome-vanadium steel 31CrV3 and features a 6-point 8 mm internal hexagon. The insert is designed with a square drive mounting in accordance with DIN 3120 - C 10 and ISO 1174, with a drive mount of 10.0 mm (3/8"). The surface is provided with two-layer Check-Tool insulation, and the insulation has an overhang of 16–18 mm.
Electrical safety
The product is VDE-insulated and specified for use up to 1000 V in accordance with EN 60900 / IEC 60900, as stated by the manufacturer.
- Material: Chrome-vanadium steel 31CrV3.
- Surface: 2-fold Check-Tool insulation.
- VDE insulation: up to 1000 V (EN 60900 / IEC 60900).
Documentation
Source: See manufacturer's product page
Specifications
- Product name: GEDORE VDE socket wrench insert VDE 30 8 (code 2946394).
- Type: VDE socket insert, 6-point, 8 mm.
- Drive: 3/8" (drive connector square [inch]: 3/8").
- Drive mount (square): 10.0 mm.
- Standards: DIN 3120 - C 10; ISO 1174; EN 60900 / IEC 60900 (specified by manufacturer).
- Material: Chrome-vanadium steel 31CrV3.
- Surface/insulation: 2-fold Check-Tool insulation, 16–18 mm insulation overhang.
- Total length: 44 mm.
- Overall width: 23 mm.
- Width across flats: 8 mm.
- Weight: 0.035 kg.
- Delivery: 1 piece per unit (Contents (Qty of pieces): 1).
The content is generated using AI – we reserve the right for errors.
Contact HIN for further information about the product.
