GEDORE VDE 30 22
The GEDORE VDE 30 22 is an insulated socket wrench insert for a 3/8" square drive, designed for manual use. It is used when working with a 22 mm hexagonal nut or bolt, and where electrical safety is also required.
It is part of GEDORE's VDE range and is insulated up to 1000 V according to EN 60900 / IEC 60900. In practice, this means it is intended for electrical work where a tool adapted for working around live parts is needed. The double Check-Tool insulation and 16–18 mm insulation protrusion are part of its construction.
The insert itself is made of chrome-vanadium steel 31CrV3, making it a classic tool for professional use in socket wrench systems. It has a 6-point profile, 44.0 mm working length, and fits a 3/8" drive with a 10.0 mm square connection according to DIN 3120 - C 10 / ISO 1174.
This is the type of insert to use when the task requires a precise fit, good access, and an electrically insulated solution in the same tool.
Typical applications
- Electro-technical assembly and service
- Tasks involving a 22 mm hexagon
- Use with a 3/8" ratchet or other compatible square drive
Specifications
- Manufacturer: GEDORE
- MPN: 2946521
- Product name: VDE 30 22
- EAN: 4010886947555
- Type: VDE-insulated socket wrench insert
- Profile: 6-point
- Wrench size: 22 mm
- Drive: 3/8"
- Square connection: 10.0 mm
- Standard: DIN 3120 - C 10 / ISO 1174
- Insulation: up to 1000 V according to EN 60900 / IEC 60900
- Material: chrome-vanadium steel 31CrV3
- Working length: 44.0 mm
- Total length: 48 mm
- Total width: 33.7 mm
- Weight: 0.105 kg
- Scope of delivery: 1 pc.
