GEDORE VDE 30 16
The GEDORE VDE 30 16 is an insulated socket for hand tools, used when working on live electrical systems. It fits a 3/8" square drive and has a 16 mm hexagon, so it can be used with a suitable ratchet, extension, or handle of the same size class.
In practice, this is a socket chosen when there is a need for safe and controlled work in control panels, installations, and other environments where the tool must be approved for live working. The combination of VDE insulation and the compact socket size makes it particularly relevant here.
The socket is made of chrome-vanadium steel 31CrV3 and features GEDORE's two-layer Check-Tool insulation. It is insulated up to 1000 V according to EN 60900 / IEC 60900, and the insulation has an overhang of 16-18 mm. This provides a clear and safe construction, designed for professional use where the tool must withstand daily handling.
It is a hand-operated socket with a hexagonal grip, so it grips nuts and bolts with 6 sides. This type of grip is suitable when you want firm contact and more secure power transmission than with a loose wrench.
Specifications
- Manufacturer: GEDORE
- MPN: 2946475
- EAN: 4010886947500
- Model: VDE 30 16
- Square drive: 3/8" / 10.0 mm
- Socket size: 16 mm
- Outer hexagon: 23 mm
- Overall length: 46 mm
- Overall width: 26.2 mm
- Insulation: up to 1000 V
- Standard: EN 60900 / IEC 60900
- Material: chrome-vanadium steel 31CrV3
- Weight: 0.06 kg
- Insulation projection: 16-18 mm
View datasheet from manufacturer
