Butane-powered mini soldering iron from WELLER
The Weller Pyropen Junior is a butane-powered mini soldering iron (Item No. T0051607599). The unit is manually ignited and performs three functions: soldering with a tip, hot air (hot blow), and open flame (torch). The product's core functions and operating principle are documented by the manufacturer and in the official product sheets.
Features and construction
- Three functions: soldering, hot air, and open flame.
- Manual ignition.
- Temperature control for soldering from 250°C to 450°C; hot air up to 430°C.
- Accepts interchangeable 71-series soldering tips.
- Comes with an aluminum protective cap with pocket clip and a safety solution that prevents the cap from being placed when the tool is on.
Documentation
The manufacturer's operating and technical information is available in the official datasheet. See datasheet from the manufacturer.
Typical applications
The description of applications is derived directly from the product's functions and manufacturer's documentation:
- Use as a soldering iron for hand soldering at adjustable tip temperatures (250°C–450°C).
- Use as a hot air blower at temperatures up to 430°C by switching to the hot air nozzle.
- Use as an open flame (torch) by removing the tip and setting the dosing ring to open flame.
Specifications
- Product name: Weller Pyropen Junior (Item No. T0051607599)
- Power supply: Butane gas (refillable)
- Ignition: Manual
- Temperature, soldering iron: 250°C - 450°C
- Temperature, hot air blower: up to 430°C
- Length incl. soldering tip: 175 mm
- Weight incl. gas filling: 56.4 g
- Burn time per filling: 0.3 hours (at gas control setting 2)
- Gas consumption: 8 g/hour
- Filling capacity: 6 ml
- Compatible tips: Interchangeable 71-series tips (list in manufacturer's documentation)
- Included: Aluminum protective cap with pocket clip and safety function
