End Cutter — TR 5000 13
The TR 5000 13 is an end cutter from PIERGIACOM with ESD order code TR 5000 13 D. The tool's primary function is the precise cutting of component leads and wires; the manufacturer specifies a medium head with an overall length of 147 mm and a steel thickness of 5 mm.
Function and Features
- End cutter design for precise flush cutting (cuts component leads 1.3 mm from the surface).
- Specified cutting force: 5.5 kg.
- Capacity for copper wire: up to Ø 1.30 mm (16 AWG) according to the manufacturer.
- Medium head (head: Medium) and handle model: St.
- ESD version available under order code TR 5000 13 D.
Typical Applications
According to the manufacturer, the TR 5000 13 is suitable for precise cutting in situations where access is difficult; the tool is described as ideal for hard-to-reach areas. The stated capacity for copper wire and the specified cutting force indicate its application area as cutting component leads and similar wires up to the stated diameter.
Specifications
- Product name: TR 5000 13.
- Manufacturer: PIERGIACOM.
- Order code (ESD): TR 5000 13 D.
- Length: 147 mm.
- Head: Medium.
- Cutting force: 5.5 kg.
- Copper wire: Ø 1.30 mm (16 AWG).
- Steel thickness: 5 mm.
- Handle model: St.
- Cutting distance from surface: 1.3 mm (component leads).
