Product Overview
The Cembre TBS2.5-BU is a modular screw terminal block from CEMBRE. The product category (modular terminal block) follows directly from the product designation and describes a unit for electrical connection between conductors in modular assembly setups.
Design and Function
The TBS2.5-BU is designed as a single-pole, modular terminal block with an M2.6 screw and a 5 mm wide clamping unit. The clamping type is specified as a screw terminal, and the product is used to secure conductors by mechanical pressure from the screw. The cable stripping length is 8 mm, and the tightening torque is 0.4 Nm, indicating the recommended force when installing the screw.
Mounting and Wiring Options
- Number of connections per unit: 1.
- Total cable cross-section range: 0.14–4 mm².
- Flexible conductor (e.g., stranded): 0.14–2.5 mm².
- Solid conductor: 0.14–4 mm².
The Cembre TBS2.5-BU is supplied in a blue finish and is intended for mounting in modular rails or systems where single-pole terminal blocks are used. The stated values for tightening torque, stripping length, and wiring ranges follow the manufacturer's technical specifications for this variant.
Specifications
- Product Name: Cembre TBS2.5-BU
- Manufacturer: CEMBRE
- Type: Modular screw terminal block
- Colour: Blue
- Screw size: M2.6
- Number of connections: 1
- Width: 5 mm
- Cable cross-section (total): 0.14–4 mm²
- Flexible conductor: 0.14–2.5 mm²
- Stripping length: 8 mm
- Tightening torque: 0.4 Nm
- Max. current (nominal cross-section, IEC EN 60947-7-1): 24 A
